Variable Message Signs - Trailers

VMS TRAILERS

MOBILE VMS TRAILER WITH AMBER DISPLAY

The versatility of an Aldridge amber VMS Trailer means that it can be used for many different applications such as advance warning messages (AWS), traffic calming, speed radar advisory, real-time programming and general advertising.

Diverse – Remote management and GPS location over cellular internet connection
Durable – Fully galvanised trailer, powder-coated paint and solid-state electronics throughout.
Reliable – Yes, definitely! We have a proven track record.
Cost Effective – For long projects or multiple short-term projects, cheaper than hiring.
Easy to Program – Select from pre-programmed messages or type a new message, click a button and you are done.
Remote Management – Remote management and GPS location over a cellular internet connection with no additional software fee 1.
Local Support – Local after-sales support & spare parts.
Local Management – Using on-board tablet PC
Australian Standard – Built to Australian Standard 4852.2 – 2009.

  • Fully solar powered with backup battery
  • Designed to AS 4852.2-2009
  • Rotatable mechanical tilt solar panels
  • Full Matrix Display, 1 to 4 lines of text, graphics & animation
  • High quality amber LED display
  • Non-glare UV polycarbonate screen
  • Graphical programming interface for instant message preview
  • Hydraulic sign-lifting mechanism
  • Lockable storage compartment
  • Matt black panel frame with reinforced front
  • Rotatable display sign panel
  • Automatic display dimming

VMS ‘B’

  • Display size (mm) 2030 x 1400
  • Display viewing area (mm) 1830 x 1200

VMS ‘C’

  • Display size (mm) 2700 x 1800
  • Display viewing area (mm) 2400 x 1600
  • Road works
  • Events/crowd control
  • Police/community safety messages
  • Advertising

MOBILE VMS TRAILER WITH 5 COLOUR DISPLAY

ATS Variable Message Sign 5-Colour – is a trailer-mounted self-powered VMS board with remote messaging and radar speed display capabilities. The VMS can display multi-message full graphics in various font styles. It utilises high-brightness LED technology for superior visibility in all light conditions.

Diverse – Remote management and GPS location over a cellular internet connection
Durable – Fully galvanised trailer, powder-coated paint and solid-state electronics throughout.
Reliable – Yes, definitely! We have a proven track record.
Cost Effective – For long projects or multiple short-term projects, cheaper than hiring.
Easy to Program – Select from pre-programmed messages or type a new message, click a button and you are done.
Remote Management – Remote management and GPS location over a cellular internet connection with no additional software fee 1.
Local Support – Local after-sales support & spare parts.
Local Management – Using on-board tablet PC
Australian Standard – Built to Australian Standard 4852.2 – 2009.

  • Fully solar powered with backup battery
  • Designed to AS 4852.2-2009
  • Rotatable mechanical tilt solar panels
  • Full Matrix Display, 1 to 4 lines of text, graphics & animation and auto fit font
  • High quality 5 colour LED display (Yellow, Red, Green, White, Blue)
  • Non-glare UV polycarbonate screen
  • Graphical programming interface for instant message preview
  • Hydraulic sign lifting mechanism
  • Fully galvanised trailer
  • Lockable storage compartment
  • Burnt orange panel frame with reinforced front
  • Rotatable display sign panel
  • Fault reporting
  • Automatic display dimming
  • Security lockable wheels

VMS ‘B’

  • Display size (mm) 2030 x 1400
  • Display viewing area (mm) 1830 x 1200

VMS ‘C’

  • Display size (mm) 2700 x 1800
  • Display viewing area (mm) 2400 x 1600
  • Road works
  • Events/crowd control
  • Police/community safety messages
  • Advertising

EVOLIS TRAILER MOUNTED SPEED INDICATION

With over 8000 units installed worldwide, the Evolis Speed Indication Device is the product of choice for an all-in-one radar and data collection device. Not only does it present a sleek European design, it has also been built using the best components giving it a reputation for being one of the most energy-efficient and reliable units in the market.

The Mobile Evolis Speed Indication Device Trailer is easily configured and installed to educate motorists of their travel speeds. It helps to reduce overall excess traffic speeds, particularly in high-incident areas such as school zones and construction work zones. Utilising the optional built-in data logger, road asset owners can gather and analyse traffic speed data on specific roads so they can make informed planning decisions on road safety.

Display Type 3 Digit 7 Segment & Full matrix LED graphic
Display Colour Red, Amber and Green
Speed Digit Size 340mm high
Text Display Size 640mm x 160mm (60 x 16 pixels)
Housing Size 709mm (w) x 700mm (h) x 170mm (d)
Text Display 1 line of 7 character at 160mm high, 2 Lines of 10 characters at 70mm high
Viewing Distance 250m
Display Protection UV polycarbonate
IP Rating IP66
Doppler Radar 24.125 Ghz
Detection Range 10-250m
Accuracy +/- 1 km/h (travelling at 100km/h)
Power Source 12v DC 200Ah Deep Cycle Gel Battery
Solar Charging 75W Solar Panel and Solar Regulator
Trailer Size 1700mm (w) x 1950mm (h) x 2550mm (l) – Travel Position, 1700mm (w) x 2700mm (h) x 2200mm (l) – Operating Position
Weight 350Kg
Communication USB, Bluetooth or Internet via 3G modem (Remote access monthly / year subscription require in addition to normal monthly telco provider data charges)
Software User Friendly set-up EVOCOM Software
Autonomy Fully autonomous
Detection Angle 17degrees
Warranty 2 Years
  • Local & State Government Roads
  • Road Work Sites
  • School Zones
  • Shopping Centres
  • Commercial Factory Sites
  • Emergency Situations
