The Boston III ‘P’ Cat. significantly reduces energy consumption without compromising luminance. Boston is also available for ‘V’ Cat Roads (see Boston V)
Traditional-shaped Boston III is usually found in traditional suburban streets, urban areas, and streetscapes. The lantern reflector design eliminates unwanted upward light, providing higher ground-level illumination. The Boston can be Top Mounted – or Side Mounted, giving an altogether different look.
Wattages 40W, 60W, 80W, 100W
Available with ZHAGA:
ZHAGA, is the next generation of Street Lighting Controller socket, and is mounted onto our fittings and operated through a plug-and-play installation. It is the latest alternative, more compact DC connector, developed especially for today’s contemporary designed LED light fittings. Zhaga D4i Certified P-LED fittings are future-proof and available with both Zhaga and NEMA sockets. Developed according to a global lighting industry standard, Zhaga connectors can be deployed onto the P-LED range and integrated with our TST Smart City Solutions and Dali2.
- ‘P’ Category Roadways
- Suburban Roads
- Shopping Precincts
- Walkways
- Parks
- Including ‘P4’ & ‘P5’
- Driveways
- Car Parks
- Security Lighting
- Body: High Pressure Die Cast Aluminum (Marine Grade)
- Optics: P4 – P5 – T2 – T3 – T4 – T5
- LED: CREE / SAMSUNG / LUMILEDS
- Wattage: 40 – 60 – 80 – 100 Watts
- Finishing: Powder Coat (Black Standard)
- Fixing: Side-Entry (SE), Top-Entry (TE)
- IP Rating: IP65
- IK Rating: IK08
- Voltage: 220V-240V 50/60Hz
- Power Factor: >0.9
- Surge Protection Device: (SPD – 20kV / 10kA)
- Smart City Ready – TST compatibility Zigbee, LoRa, NBIoT
- High-Performance luminaire designed to meet stringent Australian Standards AS/NZS 1158.6
- Suitable for Pedestrian Area, Pathways, and Parks Lighting Applications
- High-Performance Optics designed to meet and comply with Australian standards AS1158.3.1
- Self-cleaning housing and PMMA optical diffuser
- Integrated thermal management
- 7-pin Nema Receptacle (7-Pin)
- Supports DALI-2 connection and complies with D4i
- 5-year warranty
- Zhaga: Lighting Controller
- DALI-2, D4i
- Fuse Terminal Block: (FTB)
- Class II: Double Insulated (DB)
- Color: Black (Standard), White (WH), Grey (GR)
- Visor: Glare Shield / Spill Light Kit (GV)
- CCT: 2200K, 3000K, 4000K (Standard), 5000K
- Spigot Adapter: Side Entry: Ø34mm – Ø42mm – Ø48mm
