BALLOON

TST ICON

The Balloon Post Mount ‘P’ Cat. significantly reduces energy consumption without compromising luminance.

ATS decorative luminaires provide a bright and reliable light source which serves to create inviting public spaces, whilst enhancing the character and functionality of the environment.

Designed to reflect the culture and history of the surrounding community, our lighting range includes contemporary luminaires to complement the architecture of modern developments and traditional LED street lights for the older and established suburbs. Our decorative street lighting can highlight landmarks, historical sites and other points of interest, further enhancing the local character of the neighborhood.

Wattages: 30W, 40W, 50W


Available with ZHAGA:

ZHAGA, is the next generation of Street Lighting Controller socket, and is mounted onto our fittings and operated through a plug-and-play installation. It is the latest alternative, more compact DC connector, developed especially for today’s contemporary designed LED light fittings. Zhaga D4i Certified P-LED fittings are future-proof and available with both Zhaga and NEMA sockets. Developed according to a global lighting industry standard, Zhaga connectors can be deployed onto the P-LED range and integrated with our TST Smart City Solutions and Dali2.

SUITABLE FOR ICONS
  • Suburban Roads
  • Walkways
  • Shopping Precincts
  • Parks
  • Driveways
  • Car Parks
  • Security Lighting
  • Body: High Pressure Die-cast Aluminum (Marine Grade)
  • Optics: T2 – T5
  • LED: CREE / SAMSUNG / LUMILEDS
  • Wattage: 30 – 40 – 50 Watts
  • Finishing: Powder Coat (Black Standard)
  • Globe: Polycarbonate
  • Fixing: Post Top Entry
  • IP Rating: IP65
  • IK Rating: IK08
  • Voltage: 220V-240V 50/60Hz
  • Power Factor: >0.9
  • Surge Protection Device: (SPD – 20kV / 10kA)
  • Smart City Ready – TST compatibility Zigbee, LoRa, NBIoT
  • High-Performance luminaire designed to meet stringent Australian Standards AS/NZS 1158.6
  • Suitable for Pedestrian Area, Pathways, and Parks Lighting Applications
  • High Performance Optics designed to meet and comply with Australian standards AS1158.3.1
  • Self-cleaning housing and PMMA optical diffuser
  • Integrated thermal management
  • 7-pin Nema Receptacle (7-Pin)
  • Supports DALI-2 connection and complies with D4i
  • 5 year warranty
  • Zhaga: Lighting Controller
  • DALI-2, D4i
  • Fuse Terminal Block: (FTB)
  • Class II: Double Insulated (DB)
  • Colour: Black, (Dark Grey-Standard)
  • Optics: PMMA
  • CCT: 2200K, 3000K, 4000K (Standard), 5000K
  • Spigot Adapter: ø60mm – ø76mm
